DEPA气动双隔膜泵M系列DL型隔膜泵泵产品型号北京德诺伊流体技术有限公司

品牌DEPA	有效期至长期有效	最后更新2020-06-08 15:22
浏览次数0

DEPA气动双隔膜泵M系列DL型

吴亚男
QQ：2853369884

手机：17718583804
电话：010-64714988-212
传真：010-64714988-668
邮件：tk2@handelsen.cn

吴亚男邮箱：tk2@handelsen.cn电话：010-64714988-212

DEPA气动双隔膜泵M系列DL型

操作原理

双作用，正排量M系列泵有两个交替的泵室。驱动单元的压缩空气通过控制阀依次进入每个隔膜的后部，从而将介质从交替的泵送腔室中排出。在所示的泵中，右泵腔处于吸入位置。隔膜的缩回产生了真空，泵送的介质流入腔室。左隔膜由压缩空气支撑，同时置换了该腔室中存在的介质。由于两个膜片通过一个共用的活塞杆连接，因此始终在一个腔室中发生吸力，而在另一个腔室中发生排气。

DEPA型号：

40多年来，DEPA气动隔膜泵一直是全球恶劣环境和严苛应用条件下可靠性和效率的支柱。德国DEPA系列气动隔膜泵这一高质量的正向位移泵一直应用于各个工业领域。每天，即使是在恶劣的应用条件下，这些泵在世界各地以其可靠性和性发挥着作用。在泵的生产过程中，各个工业领域对泵的质量要求、操作和维护泵的方便性一直是我们的zui高准则。先进的生产工艺、保证质量的检测系统以及DIN EN ISO29001认证，保证了DEPA产品的高质量。德国DEPA气动隔膜泵系列介绍

DEPA气动双隔膜泵系列DH-TP / TPL

DH-TP和TPL泵分别由PTFE和PTFE导电外壳材料制成。通过更新和优化的设计，泵通过其简单，坚固和坚固的结构而与众不同。通用法兰设计（JIS，ANSI和DIN组合）可实现灵活的全球部署。

DEPA气动隔膜泵，非金属泵，P系列

气动隔膜泵，单个车身部件由聚丙烯，PVDF或PTFE制成。

DEPA气动隔膜泵，铸造金属泵，M系列

DEPA?气动隔膜泵专为磨料，含固体和粘性介质的平稳转移而开发。

DEPA气动双隔膜泵，不锈钢泵，L系列，DL-SLV / SUV（食品系列）

L系列泵 - DL-SLV和DL-SUV - 由抛光不锈钢制成，表面光洁度高达Ra *3.2μm，并获得FDA（食品和药品管理局）批准的弹性体。DL-SLV / SUV型适用于关键食品应用。

DEPA气动双隔膜泵，不锈钢泵，L系列，DL-SFS / SF型（食品线）

L系列泵 - DL-SFS型和DL-SF型 - 由电抛光铸造不锈钢制成，表面光洁度高达Ra *3.2μm，并获得FDA（食品和药品管理局）批准的弹性体。DL-SF / SFS型适用于一般食品应用。

DEPA气动隔膜泵，不锈钢泵，L系列无菌生产线，由EHEDG认证

允许在无菌过程中的各种应用，特别是在制药和保健行业。

DEPA气动隔膜泵，高压泵，DB系列

DEPA气动隔膜泵是压力保持操作的一种经济有效的替代方案，因为省去了任何精细和昂贵的闭环或开环控制。

DEPA气动隔膜泵，附件/自动化

DEPA气动隔膜泵可为各种应用配备各种附件，即使在自动化领域也是如此。

DEPA DH新一代气动双隔膜泵

DEPA DD新一代气动双隔膜泵系列DH15，DH25，DH40，DH50和DH80由工业应用开发的铸铝制成。

DEPA DH新一代铸造不锈钢气动双隔膜泵

DEPA DD新一代气动双隔膜泵系列DH15，DH25，DH40，DH50和DH80由工业应用开发的铸铝制成。

DEPA DB40-CA-DEE

DEPA DL40-SA-TTT

DEPA DL50-AA-TTT

DEPA DL50-AA-EEE

DEPA DL80-AA-TTT

DEPA DL25-PP-TTT

DEPA DP 40

DEPA DP 50

DEPA DP 80

DEPA DP 125

DEPA DB 25

DEPA DB 40

DEPA DB 50

DEPA DZ 15

DEPA DZ 25

DEPA DZ 40

DEPA DZ 50

DEPA DH15

DEPA DH25

DEPA DH40

DEPA DH50

DEPA DL 15

DEPA DL 25

DEPA DL 40

DEPA DL 50

DEPA DL 80

co-ax同轴阀MK / FK 32 DR

特性

端口螺纹 G 1 1/4 - G 1 1/2

法兰 PN 16/40

功能 NC

压力范围 0-16 / 0-40 bar

A B max. 40 bar

B A max. 16 bar

A C max. 40 bar

C A max. 16 bar

KV值 A B 14,1 m³/h

A C 8,9 m³/h

介质气态液态高粘稠凝胶状高污染

流向见压力范围

开关周期 120 1/min

开关时间打开 440 ms

关闭 250 ms

介质温度 DC -20 °C — +100 °C

AC -20 °C — +100 °C

环境温度 DC -20 °C — +80 °C

AC -20 °C — +80 °C

重量 MK 18,0 kg

FK 22,0 kg

标称电压 Un 24 V DC

Un 230 V 40-60 Hz AC

驱动 DC 直流电磁铁

AC 内置式整流器的直流电磁铁

绝缘等级 H 180 °C

防护等级 IP65

负载率 ED 100%

连接按DIN EN175301-803标准的插头, 形式A 4个位置X90°, 电线直径 6-8 mm

阀门的设计是基于介质和工况的要求.这些因素可能导致设计、密封材料和特性与通用参数表上的规格有所不同.
