BIERI密封阀WVM-6i介绍
吴亚男 QQ:2853369884 手机:17718583804 电话:010-64714988-212 传真:010-64714988-668 邮件:tk2@handelsen.cn |
BIERI系列WVM-6I由直接电磁操作的无泄漏阀组成,适用于高负载循环。主要部件的模块化原理允许各种各样的电路符号:2 / 2-,3 / 2-,3 / 3-,4 / 2-,4 / 3-和4/4路功能,带正极和也是负面重叠。因此,这些阀门是滑阀的优越且节省空间的替代品,可能需要额外的无泄漏截止阀。
特征好处
锥形/阀座元件的专利在线排列:更少的组件,紧凑的设计,更高的可靠性和各种功能
阀锥压力补偿设计,高磁力和强回位弹簧:安全快速切换,开启换档位置双向流动,双闭合,关闭位置无泄漏密封
硬化座椅元件(锥形和座椅):使用寿命长,可靠性高
360°可转动和可更换的插入式线圈:电磁线圈的任意位置,更换线圈而不打开压力密封空间
镀锌镍线圈,阀体由耐腐蚀热处理钢制成:高耐腐蚀性
止回阀和孔可以集成在一起:可以轻松实现多种选择
细分与应用
夹紧技术和夹具结构
机床 - 辅助功能
成型技术 - 夹紧
小型印刷机
起重运输系统
液压工具
测试台和系统
施工
回收
被动和/或主动逻辑阀的座椅紧固先导控制
节能电路
蓄电池充电电路
设计
专利功能原理
压力补偿设计的硬化和特殊研磨阀锥
强劲的弹簧
隐藏的手动覆盖
止回阀和孔可以集成在一起
提供2 / 2-,3 / 2-,3 / 3-,3 / 4-,4 / 2-,4 / 3-或4/4阀
带有图案的板式安装阀,符合ISO4401-03标准
360°可转动和可更换的插入式线圈
更换线圈而不打开压力密封空间(滑入式线圈)
技术数据
液压油矿物油符合DIN 51524(可根据要求提供其他液体)
流体温度范围-20至80°C
环境温度范围-20至400°C
粘度范围5至400 mm 2 / s
密封材料FKM
移植NG 6符合DIN 24340 / ISO 4401 / CETOP RP 121 H
最大。工作压力连接P,A,B500巴
最大。工作压力连接T.70吧
最大。流量25升/分钟 -
过滤(推荐)根据NAS 1638,第6类和 ISO / DIN 4406 Klasse 17/15/12
占空比ED100%
电磁阀电压24 VDC(30 W)
公差+/- 10%
切换时间40 - 110毫秒
防护等级符合DIN 40050的IP 65(或根据线圈选择)
重量1.7千克(1个线圈),2.2千克(2个线圈)
材料/表面处理阀体:耐腐蚀钢
电磁线圈:镀ZnNi
BIERI BKP110.47汉700达14森250PC*00
BIERI BKP110.47汉700达32.9森220PC*00
BIERI BKP110.47汉700达4森250PC*00
BIERI BKP110.47汉700达6森250PC*00
BIERI BKP110.68汉700达8.5森250PC*00
BIERI BKP110.79汉700达14森250EC*02
BIERI BKP110.79汉700达22.3森190PC*00
BIERI BKP111.03汉700达11森250PC*00
BIERI BKP111.03汉700达8.5森250PC*00
BIERI BKP111.1汉700达4森250PC*00
BIERI BKP111.1汉700达6森250PC*00
BIERI BKP111.13汉1000达6森250PC*00
BIERI BKP111.21汉700达11森250PC*00
BIERI BKP111.21汉700达16.5森250汉230PC*00
BIERI 6BKP111.21汉700达6森220汉250PC*00
BIERI BKP111.21汉700达61.1森250汉180PC*00
BIERI BKP111.53汉1000达11森250汉250PC*00
BIERI BKP111.53汉1000达8.5森250汉250PC*00
BIERI BKP111.53汉700达11森250汉250PC*00
BIERI BKP111.53汉700达19.5森190汉210PC*00
BIERI BKP111.53汉700达6森250汉250PC*00
BIERI BKP111.53汉700达8.5森250汉250PC*00
BIERI BKP111.58汉700达11森250汉250PC*00
BIERI BKP111.58汉700达6森250汉250PC*00
BIERI DV700-6-E-700-P BIERI电磁阀液压工具
BIERI DV700-6-E-700-P-A*00 BIERI电磁阀 液压工具
BIERI ERV700-6-AB-P-A*00 BIERI电磁阀 油田
BIERI FS-34203 BIERI电磁阀电厂
BIERI WV700-6-2汉2-VO-24-P-A*00 BIERI电磁阀 油田
BIERI WV700-6-2汉2-VO-24-P-A*00 BIERI电磁阀 油田
BIERI WV700-6-2汉2-VO-24-P-A*00 BIERI电磁阀 电厂
BIERI WV700-6-2汉2-VO-24-P-A*00 BIERI电磁阀 造船
BIERI WV700-6-2汉2-VO24-P-A00 BIERI电磁阀 医疗器械
BIERI WV700-6-2汉2-VO-24-P-AB00 BIERI电磁阀 液压工具
BIERI WV700-6-2汉2-VS-24-P-B*00 BIERI电磁阀 医疗器械
BIERI WV700-6-2汉2-WS-24-P-B*00 BIERI电磁阀 造船
BIERI WV700-6-3汉3-K-24-V-A*00 BIERI电磁阀 造船
BIERI WV700-6-4汉2-D-24-P-A*00 BIERI电磁阀 钻井平台
BIERI WV700-6-4汉2-D-24-P-A*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉2-D-24-P-Af00 BIERI电磁阀 医疗器械
BIERI WV700-6-4汉3-E-24-P-AG00 BIERI电磁阀 钻井平台
BIERI WV700-6-4汉3-E-24-P-B*00 BIERI电磁阀 医疗器械
BIERI WV700-6-4汉3-H-24-P-A*00 BIERI电磁阀 造船
BIERI WV700-6-4汉3-H-HR-P-00 BIERI电磁阀 电厂
BIERI WV700-6-4汉3-J-24-P-A*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉3-J-24-P-A*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉3-J-24-P-AH00 BIERI电磁阀 医疗器械
BIERI WV700-6-4汉3-P-24-P-A*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉3-U-24-P-B*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉3-U-24-P-B*00 BIERI电磁阀 液压工具
BIERI WV700-6-4汉3-U-24-P-B*00 BIERI电磁阀 钻井平台
BIERI WV700-6-4汉3-U-24-V-B*00 BIERI电磁阀 医疗器械
BIERI WVH700-4-2汉2-WS-24-P-AE00 BIERI电磁阀 液压工具
BIERI WVH700-4-3汉2-L-24-P-A00 BIERI电磁阀 电厂
BIERI BRK01汉1.53达1000-P-B*00
BIERI BRK11汉1.83达1000-P-B*00
BIERI BRK11汉1.88达700-P-A*00
BIERI BRK701汉1,88达700-V-C*00
BIERI BRK11汉1,83达700-P-B*00
BIERI BRK701汉1,88达700-P-C*01
BIERI BRK11汉1.88达900-P-B*00
BIERI BRK11汉2.83达700-P-A*00(已停产)
BIERI BRK701汉2,81达700-V-C*00
BIERI BRK701汉3.14达700-P-C01(替代号)
BIERI BRK12汉6.33达650-P-B*00
BIERI BRK12汉6.33达850-P-Ad00
BIERI DV7.250汉33025
BIERI DV7.60达33006
BIERI DV700-6森P350-P
BIERI DV700-6-P700-P
BIERI DV700-6-P-700-P-A*00
BIERI ERV700-6-A-P-A*00
BIERI PDV700-6-P-700-2-P-00
BIERI SBV700-6-A-350-P-A*00
BIERI SF-34201
BIERI WV700-6-2汉2-VO-24-P-A*00
BIERI WV700-6-4汉2-D-24-P-A*00
BIERI WV700-6-4汉3-E-24-P-B*00
BIERI WV700-6-4汉3-H-24-P-A*00
BIERI WV700-6-4汉3-H-HR-P-00
BIERI WV700-6-4汉3-J-24-P-A*00
BIERI WV700-6-4汉3-P-24-P-A*00
BIERI BRK-2.02汉700-P-A*00
BIERI ERV700-6-E-P-A*00
BIERI SRK11-ATEX-6.33汉350V-BCOO
BIERI SRK701-ATEX-6,33达350-V-C*00
BIERI SRK11-6.33汉350-V-A*00
BIERI DV700-6-E汉700-P-A*00
BIERI WV700-6-4汉3-U-24-P-B*00
BIERI BKP11汉3.5达650森8.5-250-P-C*00
BIERI SKP01-0.5汉700达4.5森70-P-A*00
BIERI SKP03汉0,45达700森4,45汉100-P-B*00
BIERI BRK11汉0.68达700-P-B*00
BIERI (BRK701汉0.60达700-V-C*00)
BIERI BRK11汉1.03达700森P-B*00
BIERI (BRK701汉0.76达700森V-C*00)
BIERI BRK11汉1.21达700森P-B*00
BIERI (BRK701汉1.03达700森VC*00)
BIERI BRK11汉0.47达700森PB*00
BIERI BRK11汉0.47达1000森PB*00
BIERI (BRK701汉1.21达700森VC*00)
BIERI BRK11汉0.68达1000森PB*00
BIERI (BRK701汉0.47达700森VC*00)
BIERI BRK11汉0.79达700森PB*00
BIERI (BRK701汉0.79达700森VC*00)
BIERI WV700汉6达2汉2森VS7PB*00
BIERI WV700汉6达2汉2森WS24PB*00
BIERI SKP01汉0.8达700森6.81汉000PA*00
BIERI BRK12汉4.4达900森PAB00
BIERI MRK701汉4x0.23达1000森PA*00
BIERI MRK11汉4*0.76达700森PAa01
BIERI MRK701汉0,76达0,76森0,760,汉76700V
BIERI WVH700汉4达3汉2森L24PA00
BIERI WVH700汉4达2汉2森WS24PAE00
BIERI KKP02汉0.17达700森2.0260PA*00
BIERI SRK701汉ATEX达6.33森350VC*00
BIERI AKP103汉0.1达500森PA*OO
BIERI WV700-6-2汉2-VO-24-P-A*00
BIERI HSV700-6-4汉3-H-HR-P-A*00
BIERI HSV700-6-4汉3-H-HR-V-A*00 4汉3-Wege
BIERI WV700-6-4汉3-u-24-P-B*00
BIERI BRK12汉6.33达650森P-B*00原型号停产,新型号BRK702汉6.33达650森V-C*00
BIERI AKP30汉0.02达300-V-A*00 油田
BIERI WV700-6-4汉3-U-24-V-B*00
BIERI SRK11汉6.33达350-V-A*00
BIERI SBV700-6-A-350-P
BIERI WV700-6-3汉3-K-24-V-A
BIERI AV700-6-E-25-P
BIERI BRK501汉2.54达500森P-CC00
BIERI BRK501汉2.54达500森E-C*02
BIERI BRK12汉633达650森P-Bf00 1
BIERI HSV700-6-4汉3-UC-HR-P-A*00
BIERI MRK701汉4*0.9达700森V-00 2
BIERI WV700-6-4汉3-H-24-V-A*00 3
BIERI ERV700-6-AB-V-A*00 2
BIERI RVH-G1汉4-A-V-A*00 2 查到型号是RVH700
BIERI PDV700-6-P-700汉2-24-V-B*00 3
BIERI WV700-6-2汉2-VO-24-P-A*00
BIERI WV700-6-4汉3-U-24-V-B**00
BIERI WV700-6-2汉2-VO-24-V
BIERI DV7.250汉33025
BIERI BRK12汉6.3达850-P-Ad00 实际 BRK12森6,33-850-P-B*03
BIERI BKP701汉153达700森8--250 实际 BKP701汉1,53达700-8,5森250-V-C*00 单价
BIERI WVH700-4-2汉2-WS-24-V 实际 WVH700-4-2汉2-WS-24-V-B*00
BIERI WVH700-4-3汉2-L-24-V-BE 实际 WVH700-4-3汉2-L-24-V-BE*00
BIERI BRK12-6.33汉850-P-Ad00 实际 BRK12-6,33-汉50-P-B*03
BIERI wvh700..4.2汉2 ws-24v 实际 WVH700-4-2汉2-WS-24-V-B*00
BIERI HSV700-6-4汉3-H-HR-P-A*00
BIERI DV7.250汉29025
BIERI PDV700-6-P-700汉25-24V 实际PDV700-6-P-700汉25-24VB**00
BIERI DV700-6-E-700-D-V-A00 实际DV700-6-E-700-DPA**00
BIERI WV700-6-2汉2-W0-C-24V 实际WV700-6-2汉2-W0-24-PA*00
BIERI DV700-6-P-700-P-AE00
BIERI DA700-6-A-350-P-AG00 实际DA700-6-A-350-P-A*00
BIERI WV700-6-2汉2-WS-P-AK00 实际WV700汉622WS24PAK0
BIERI BRK11汉1.88达700-P-A*00
BIERI BRK701汉1,88达700-V-C*00
BIERI HSV700-6-4汉3-H-HR-P-A*00
BIERI WV700-6-4汉3-U-24-P-B*00
BIERI BKP111.58汉700达61.1森2501汉80PC*00
BIERI BKP111.66汉700达11森250汉250PC*00
BIERI BKP111.66汉700达14森230汉250PC*00
BIERI BKP111.66汉700达16.5森250汉230PC*00
BIERI BKP111.66汉700达19.5森180汉210PC*00
BIERI BKP111.66汉700达22.3森250汉190PC*00
BIERI BKP111.66汉700达8.5森250汉250PC*00
BIERI BKP111.83汉700达11森250汉250PC*00
BIERI BKP111.83汉700达14森2102汉50PC*00
BIERI BKP111.83汉700达19.5森250汉210PC*00
BIERI BKP111.88汉700达11森250汉250PC*00
BIERI BKP111.88汉700达14森2502汉50PC*00
BIERI BKP111.88汉700达29.3森250汉220PC*00
BIERI BKP111.88汉700达6森180汉250PC*00
BIERI BKP112.01汉1000达26森250汉170PC*00
BIERI BKP112.01汉700达19.5森250汉210PC*00
BIERI BKP112.01汉700达6森230汉250PC*00
BIERI BKP112.54汉700达11森210汉250PC*00
BIERI BKP112.54汉700达6森190汉250PC*00
BIERI BKP112.71汉700达19.5森250汉210PC*00
BIERI BKP112.71汉700达29.3森250汉220PC*00
BIERI BKP112.71汉700达6森250汉250PC*00
BIERI (BRK701汉1.03达700森VC*00)
BIERI BRK11汉0.47达700森PB*00
BIERI BRK11汉0.47达1000森PB*00
BIERI (BRK701汉1.21达700森VC*00)
BIERI BRK11汉0.68达1000森PB*00
BIERI (BRK701汉0.47达700森VC*00)
BIERI BRK11汉0.79达700森PB*00
BIERI (BRK701汉0.79达700森VC*00)
BIERI WV700汉6达2汉2森VS7PB*00
BIERI WV700汉6达2汉2森WS24PB*00
BIERI SKP01汉0.8达700森6.810汉00PA*00
BIERI BRK12汉4.4达900森PAB00
BIERI MRK701汉4x0.23达1000森PA*00
BIERI MRK11汉4*0.76达700森PAa01
BIERI MRK701汉0,76达0,76森0,760汉76700V
BIERI WVH700汉4达3汉2森L24PA00
BIERI WVH700汉4达2汉2森WS24PAE00
BIERI KKP02汉0.17达700森2.0260PA*00
BIERI SRK701汉ATEX达6.33森350VC*00
BIERI AKP103汉0.1达500森PA*OO
北京汉达森德国本土采购,拼箱发货报关,德国技术,终身售后服务,货期保证,价格公道,欢迎垂询!如需更多信息欢迎垂询汉达森品牌专员吴亚男。
