| 品牌MGV | 有效期至长期有效 | 最后更新2020-07-17 13:28 |
| 浏览次数1 |
MGV交直流主开关电源PH120-1306详情
| 薛时通 QQ：2850590583 手机：18518172429 电话：010-64717020-113 传真：010-84786709-666 邮件：sales10@handelsen.cn |
 |
960瓦输出功率■仅66mm宽■3 x 340-550VAC宽范围输入■并联负载分配■功率提升80A，最多2秒■在任何装配位置运行■一次和二次过电压保护■过热保护
产品分类
开关式电源
德国MGV Stromversorgungen GmbH电源
常用型号：
MGV 14.5942.805 SPH1013-2440* Wall mounting
MGV Type(PH30-1202) Purchase No.(15.8240.900)
MGV Type(PH30-0505) Purchase No.(15.8240.800)
MGV Powerpack 24VDC,PH15-2406 Dimensions:25*76*74mm
Input:AC94-264V 50/60HZ Output:+2％-1％，at 5V+3％
MGV PH-20034840 60V 33A 2000W
MGV Stromversorgungen GmbH PH120-1306
MGV Stromversorgungen GmbH PH1003-2440 15.8041.205
MGV Stromversorgungen GmbH DG6-05101-3G ORDER.NO
15.2946.529
MGV Stromversorgungen GmbH 250 VE 02 304-100-200
MGV Stromversorgungen GmbH DG6-05101-3G
MGV Stromversorgungen GmbH PH2003-4840
MGV Stromversorgungen GmbH PH1013-2440
MGV Stromversorgungen GmbH P3120-05121AC
MGV Stromversorgungen GmbH Power supply MGV Order
No:15.9140.253
MGV Stromversorgungen GmbH
PH803-2830;ORDER.NO.15.8044.700
MGV Stromversorgungen GmbH PH30-2401
MGV Stromversorgungen GmbH HP30-2401"
产品介绍：
AC/DC Power Supplies 15 - 250 watts
Single output
Your compact Power Supplies for DIN-Rail or wall
mounting.
Model /
data sheet Vo Io Adjustable Io Input Dimensional
drawing
PH15
24V 0.625A 94-264VAC
PH30
5V 5A 94-264VAC
PH30
12V 2.5A 94-264VAC
PH30
15V 2A 94-264VAC
PH30
21V 1.25A 94-264VAC
PH30
24V 1.25A 94-264VAC
PH70
5V 8A 5.0-5.3V 120/230VAC
PH70
13V 4A 12-15V 120/230VAC
PH70
24V 3A 22-29V 120/230VAC
PH70A
24V 3A 120/230VAC
PH120
5V 12A 5.0-5.3V 120/230VAC
PH120
13V 6.5A 12-15V 120/230VAC
PH120
24V 5A 22-29V 120/230VAC
PH120
PH120A
24V 5A 120/230VAC
SPH240
24V 10A 120/230VAC
SPH240
27,2V 10A 120/230VAC
SPH240
41V 5A 120/230VAC
SPH240
48V 5A 120/230VAC
SPH240V
24V 10A 23-28V 120/230VAC
PH251A
24V 10A 120/230VAC
PH251
24V 10A 22-29V 120/230VAC
buy: AC/DC Power Supplies 15 - 250 watts
产品系列：
AC/DC Power Supplies 15 - 250 watts
Single output
Your compact Power Supplies for DIN-Rail or wall
mounting.
Model /
data sheet Vo Io Adjustable Io Input Dimensional
drawing
PH15 24V 0.625A 94-264VAC
PH30 5V 5A 94-264VAC
PH30 12V 2.5A 94-264VAC
PH30 15V 2A 94-264VAC
PH30 21V 1.25A 94-264VAC
PH30 24V 1.25A 94-264VAC
PH70 5V 8A 5.0-5.3V 120/230VAC
PH70 13V 4A 12-15V 120/230VAC
PH70 24V 3A 22-29V 120/230VAC
PH70A 24V 3A 120/230VAC
PH120 5V 12A 5.0-5.3V 120/230VAC
PH120 13V 6.5A 12-15V 120/230VAC
PH120 24V 5A 22-29V 120/230VAC
PH120
PH120A 24V 5A 120/230VAC
SPH240 24V 10A 120/230VAC
SPH240 27,2V 10A 120/230VAC
SPH240 41V 5A 120/230VAC
SPH240 48V 5A 120/230VAC
SPH240V 24V 10A 23-28V 120/230VAC
PH251A 24V 10A 120/230VAC
PH251 24V 10A 22-29V 120/230VAC
AC/DC 19“
Single output 60 - 360 watts
Plug-in Power Supplies for your 19-inch application.
Model /
data sheet Vo Io Input dimensions Dimensional
drawing
P60 5V 10A 90-264VAC 6HP / 3U
P60 12V 5A 90-264VAC 6HP / 3U
P60 15V 4A 90-264VAC 6HP / 3U
P60 24V 2.5A 90-264VAC 6HP / 3U
P90 5.1V 14A 94-264VAC 8HP / 3U
P90 12V 7.5A 94-264VAC 8HP / 3U
P90 15V 6.5A 94-264VAC 8HP / 3U
P90 24V 4.2A 94-264VAC 8HP / 3U
