德国CO-AX同轴阀 FK 20
| 武志鹏 QQ：2850590584 手机：17718588643 电话：010-64714988-214 传真：010-64714988668 邮件：tk3@handelsen.cn |
 |
德国CO-AX公司成立于1960年，以生产同轴阀著称，凭借丰富的经验，可靠而经过严格测试的材质，过硬的质量管理，CO-AX的阀广泛适用于真空、气态、液态、胶状、磨粒、污染性以及侵蚀性等各种介质。与常规阀相比，同轴阀能够以高流量来控制高压介质，有两位两通和三位两通可选，连接方式允许螺纹连接和法兰连接，可通过直动式螺线管和外部直接控制
COAX电磁阀、COAX电动调节阀、COAX气动调节阀、COAX自力式调节阀、COAX温度调节阀、COAX压力调节阀、COAX电动球阀、COAX气动球阀、COAX电动蝶阀、COAX气动蝶阀及真空泵
FK系列
介质 气态 液态 高粘稠 凝胶状 高污染
流向 见压力范围
开关周期 20 1/min
开关时间 打开 600 ms
关闭 800 ms
介质温度 DC -20 °C — +80 °C
AC -20 °C — +80 °C
环境温度 DC -20 °C — +80 °C
AC -20 °C — +80 °C
重量 48,8 kg
标称电压 Un 24 V DC
Un 230 V 40-60 Hz AC
驱动 DC 直流电磁铁
AC 内置式整流器的直流电磁铁
绝缘等级 H 180 °C
防护等级 IP65
负载率 ED 100%
连接 按DIN EN175301-803标准的插头, 形式A 4个位置X90°, 电线直径 6-8 mm
阀门的设计是基于介质和工况的要求.这些因素可能导致设计、密封材料和特性与通用参数表上的规格有所不同.
